s8 ov 210 - Tech Specs
![](https://www.masierogroup.com/wp-content/uploads/2021/05/ola-S8-OV-210-tecnica-2024-1.png)
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
8XE14X10W
Traditional (USA):
STANDARD LIGHTING: 8XE12X40W max
INTEGRATED LED LIGHTING: UP 16,4W CRI>90 3000K 2400LM; DOWN: 49,2W CRI>90 3000K 7200LM; DIMMABLE: 0-10V
Led 3000k:
UP: 15,6W CRI>95 3000K - 1536 nominal LM
DOWN: 70,2W CRI>95 3000K - 6912 nominal LM
Led 2700k:
UP: 15,6W CRI>95 2700K - 1464 nominal LM
DOWN: 70,2W CRI>95 2700K - 6588 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBSLed:
0-10 VDimensions
H | 20 cm | 7.87'' |
---|---|---|
D | 20 cm | 7.87'' |
W | 210 cm | 82.67'' |
Certifications
Traditional Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
Led Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
s6 ov 160 - Tech Specs
![](https://www.masierogroup.com/wp-content/uploads/2021/05/ola-S6-OV-160-tecnica-2024-1.png)
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
6XE14X10W
Traditional (USA):
STANDARD LIGHTING: 6XE12X40W max
INTEGRATED LED LIGHTING: UP: 22,6W CRI>90 3000K 2770LM; DOWN: 45,2W CRI>90 3000K 5600LM 0-10V
Led 3000k:
UP: 10,4W CRI>95 3000K - 1024 nominal LM
DOWN: 50,7W CRI>95 3000K - 4992 nominal LM
Led 2700k:
UP: 10,4W CRI>95 2700K - 976 nominal LM
DOWN: 50,7W CRI>95 2700K - 4758 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBSLed:
0-10 VDimensions
H | 20 cm | 7.87'' |
---|---|---|
D | 14 cm | 5.50'' |
W | 160 cm | 63.00'' |
Certifications
Traditional Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
Led Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
s4 ov 100 - Tech Specs
![](https://www.masierogroup.com/wp-content/uploads/2021/05/ola-S4-OV-100-tecnica-2024-1.png)
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
4XE14X10W
Traditional (USA):
STANDARD LIGHTING: 4XE12X40W max
INTEGRATED LED LIGHTING: UP 4W CRI>90 3000K 690LM; DOWN: X23,2W CRI>90 3000K 3450LM; DIMMABLE: 0-10V
Led 3000k:
UP: 5,2W CRI>95 3000K - 512 nominal LM
DOWN: 25,35W CRI>95 3000K - 2496 nominal LM
Led 2700k:
UP: 5,2W CRI>95 2700K - 488 nominal LM
DOWN: 25,35W CRI>95 2700K - 2379 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBSLed:
1-10 VDimensions
H | 20 cm | 7.87'' |
---|---|---|
D | 13 cm | 5.12'' |
W | 100 cm | 39.37'' |
Certifications
Traditional Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
Led Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
s2 ov 50 - Tech Specs
![](https://www.masierogroup.com/wp-content/uploads/2021/05/ola-S2-OV-50-tecnica-2024.png)
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
2XE27X20W
Traditional (USA):
STANDARD LIGHTING: 2XE26X60W max
INTEGRATED LED LIGHTING: UP 9,2W CRI>90 3000K 1285LM; DOWN: 9,2W CRI>90 3000K 1285LM; DIMMABLE: 0-10V
Led 3000k:
UP: 5,2W CRI>95 3000K - 512 nominal LM
DOWN: 7,8W CRI>95 3000K - 768 nominal LM
Led 2700k:
UP: 5,2W CRI>95 2700K - 488 nominal LM
DOWN: 7,8W CRI>95 2700K - 732 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBSLed:
1-10 V + PUSHDimensions
H | 18 cm | 7.09'' |
---|---|---|
D | 8 cm | 3.14'' |
W | 50 cm | 19.69'' |
Certifications
Traditional Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
Led Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
s1 ov 30 - Tech Specs
![](https://www.masierogroup.com/wp-content/uploads/2021/05/ola-S1-OV-30-tecnica-2024.png)
Finishing
Materials
Painted metal structure with pendants
Light source
Traditional:
1XE14X10W
Traditional (USA):
STANDARD LIGHTING: 1XE12X40W max
INTEGRATED LED LIGHTING: UP 5,5W CRI>90 3000K 820LM; DOWN: 5,5W CRI>90 3000K 820LM; DIMMABLE: 0-10V
Led 3000k:
UP: 4W CRI>95 3000K - 390 nominal LM
DOWN: 4W CRI>95 3000K - 390 nominal LM
Led 2700k:
UP: 4W CRI>95 2700K - 375 nominal LM
DOWN: 4W CRI>95 2700K - 375 nominal LM
Dimming control
Standard:
TRIAC ONLY WITH DIMMABLE BULBSLed:
1-10 V + PUSHDimensions
H | 18 cm | 7.09'' |
---|---|---|
D | 7 cm | 2.75'' |
W | 30 cm | 11.81'' |
Certifications
Traditional Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
Led Light:
![](/wp-content/themes/masiero/imgs/iecee.png)
